Morelli | Arcieri Arquitectura
Arcieri Arquitectura,Release Time2023-10-19 10:04:33
Project Name: Morelli
Design: Arcieri Arquitectura
Located in a central area of Montevideo city, Morelli residential building is implanted in a property of 10 meters wide and 46 meters deep between walls. Taking as a reference the R2B1 zoning of Buenos Aires - our neighboring city- to make the most of the characteristics of the land, the project is divided into two 4 levels blocks, around a large central courtyard of 11 meters long. The two volumes reach the height of 9 meters permitted by city regulations, plus a rooftop terrace for recreation, and are linked to each other by an exterior circulation of concrete platforms.
The building’s access is through a basement where garages are located. There you meet the vertical circulation that leads to the fifteen bi-oriented housing units in the three upper levels.
The typologies vary between 1 and 2 bedrooms and a studio apartment, and all have terraces or patios for individual use. The arrangement around the central open space allows all the units to have a double orientation to the northwest and southeast, ensuring adequate sunlight and cross ventilation.
As we continue through the central circulation, we access the walkable roof, which has a recreation area with two barbecues for common use, and a space for tenders and water tanks.
Regarding to the design, the search was for a contemporary aesthetic of pure lines and simple volumetry. The construction was carried out with precast concrete pieces and assembled on site with the help of cranes, a solution that provided speed and simplicity to the execution.
The main façade consists of a metallic skin of steel profiles and orsogril panels attached to the building, generating a 1.20-meter-wide buffer space that functions as a green filter, providing privacy to the units and housing the outdoor spaces.
![21c6a0124cf48179fb67.jpg](https://designverse-files.oss-cn-shanghai.aliyuncs.com/21c6a0124cf48179fb67.jpg)
![843874a72914903b2e83.jpg](https://designverse-files.oss-cn-shanghai.aliyuncs.com/843874a72914903b2e83.jpg)
![49c740e23e243a5aa07a.jpg](https://designverse-files.oss-cn-shanghai.aliyuncs.com/49c740e23e243a5aa07a.jpg)
![746a81ea6074290b243a.jpg](https://designverse-files.oss-cn-shanghai.aliyuncs.com/746a81ea6074290b243a.jpg)
![d7a72f52b6844358e8e8.jpg](https://designverse-files.oss-cn-shanghai.aliyuncs.com/d7a72f52b6844358e8e8.jpg)
![031564addba4e879fe90.jpg](https://designverse-files.oss-cn-shanghai.aliyuncs.com/031564addba4e879fe90.jpg)
![fcae13af68c4b5a869e2.jpg](https://designverse-files.oss-cn-shanghai.aliyuncs.com/fcae13af68c4b5a869e2.jpg)
![85fcd92acd1473284f68.jpg](https://designverse-files.oss-cn-shanghai.aliyuncs.com/85fcd92acd1473284f68.jpg)
![5e58732c4d44753a1569.jpg](https://designverse-files.oss-cn-shanghai.aliyuncs.com/5e58732c4d44753a1569.jpg)
![cec9fc24a484808905dc.jpg](https://designverse-files.oss-cn-shanghai.aliyuncs.com/cec9fc24a484808905dc.jpg)
![62571734c324cec8d953.jpg](https://designverse-files.oss-cn-shanghai.aliyuncs.com/62571734c324cec8d953.jpg)
![a1dce5d4cd140309523d.jpg](https://designverse-files.oss-cn-shanghai.aliyuncs.com/a1dce5d4cd140309523d.jpg)
![35d80394c9f41d1ba216.jpg](https://designverse-files.oss-cn-shanghai.aliyuncs.com/35d80394c9f41d1ba216.jpg)
![d52ced1cae34cebba95a.jpg](https://designverse-files.oss-cn-shanghai.aliyuncs.com/d52ced1cae34cebba95a.jpg)
![ad9a4a2528a4ce78f755.jpg](https://designverse-files.oss-cn-shanghai.aliyuncs.com/ad9a4a2528a4ce78f755.jpg)
![71ed50b7ca94f579e163.jpg](https://designverse-files.oss-cn-shanghai.aliyuncs.com/71ed50b7ca94f579e163.jpg)
![7497b09f40d4579abbc7.jpg](https://designverse-files.oss-cn-shanghai.aliyuncs.com/7497b09f40d4579abbc7.jpg)
![399000ed10f4029ad1de.jpg](https://designverse-files.oss-cn-shanghai.aliyuncs.com/399000ed10f4029ad1de.jpg)
![68140a3817a47aba4fbb.jpg](https://designverse-files.oss-cn-shanghai.aliyuncs.com/68140a3817a47aba4fbb.jpg)
![0b66938be4c411e86b6a.jpg](https://designverse-files.oss-cn-shanghai.aliyuncs.com/0b66938be4c411e86b6a.jpg)
![3797f7006c44aaaab145.jpg](https://designverse-files.oss-cn-shanghai.aliyuncs.com/3797f7006c44aaaab145.jpg)
![a3bbcc9173143af90386.jpg](https://designverse-files.oss-cn-shanghai.aliyuncs.com/a3bbcc9173143af90386.jpg)
![747cdb3b50a4216a48ee.jpg](https://designverse-files.oss-cn-shanghai.aliyuncs.com/747cdb3b50a4216a48ee.jpg)
![40ee879243d42438a55a.jpg](https://designverse-files.oss-cn-shanghai.aliyuncs.com/40ee879243d42438a55a.jpg)
![2e30d8dcf96437081726.jpg](https://designverse-files.oss-cn-shanghai.aliyuncs.com/2e30d8dcf96437081726.jpg)
![dcdc4f375d84a82aedbf.jpg](https://designverse-files.oss-cn-shanghai.aliyuncs.com/dcdc4f375d84a82aedbf.jpg)
![da30b96704243ad94ab9.jpg](https://designverse-files.oss-cn-shanghai.aliyuncs.com/da30b96704243ad94ab9.jpg)
![f83dd1e6e7f404fb4434.jpg](https://designverse-files.oss-cn-shanghai.aliyuncs.com/f83dd1e6e7f404fb4434.jpg)
![1194a74e2b04d6e88478.jpg](https://designverse-files.oss-cn-shanghai.aliyuncs.com/1194a74e2b04d6e88478.jpg)
![f526262e8e9489db12bf.jpg](https://designverse-files.oss-cn-shanghai.aliyuncs.com/f526262e8e9489db12bf.jpg)
